Panther DS16

full-rugged 10" tablet
Panther DS16

full-rugged 10" tablet

Panther DS16P

Міцний 10“ планшет-ПК

The compact Panther series features the lightweight DS16P tablets, without losing robustness and high performance for mobile operations. The 10” form factor is based on the Intel® Meteor Lake platform, the Intel® Core™ Ultra 7 and the Intel® Graphics which are integrated in a fully rugged aluminium housing. The DS16P has an integrated, IP-protected fan to ensure maximum performance.
The Panther series comes with a wide selection of customization options. In addition to the DC-In, interfaces from COM, GLAN, audio, headset can also be designed as military Fischer connectors for even greater robustness. This also allows the devices to be expanded and combined with a wide range of peripherals and other devices. When it gets tough out in the field you don’t have to worry, the DS16 is IP65 rated as well as certified to both MIL-STD-810 and MIL-STD-461 standards.

Технічні характеристики

Display

  • LCD 10.1“ WUXGA (1920 x1200)
  • Sunlight readable
  • up to 1200 cd/m²

Touch

  • Capacitive multi touch screen
  • Optional: Resistive multi touch screen

CPU

  • Intel® Core™ Ultra 7 155U processor, 12 MB cache, up to 4.80 GHz

Chipset

  • Intel® Meteor Lake platform

Graphics

  • Intel® Graphics

Memory

  • up to 64 GB DDR5-5600

Storage

  • M.2 2242 PCIe SSD slot (up to 1 TB)

Audio

  • HD Audio and Mono Speakers
  • Optional: Embedded Digital Mic

Keys

  • 13 Function keys with 5 programmable keys

Interfaces

  • 1x USB3.2 Gen.2 (Type-A)
  • 1x Thunderbolt™ 4 (Type-C)
  • 1x 2.5G LAN (RJ45)
  • 1x DC-in (3-Pin) 19 VDC
  • 1x micro SD card slot
  • 1x nano SIM card slot
  • 1x docking connector for DockLite DS
  • Optional: 1x DockLite DLDS port replicator
  • Optional: up to 4x MIL Fischer connector possible
    • 1x USB2.0, 1x Audio, 1x 2.5G LAN, 2x COM

Connectivity [WLAN / BT / GPS]

  • Optional:
    • Intel® Wi-Fi 6E AX210 (802.11ax)
    • Bluetooth® 5.3
    • U-blox NEO-M9N (GPS/GLONASS/Galileo/Beidou)

Power supply

  • Li-ion battery, 11.61 V, 5000 mAh
    Fast Charging via USB-C
    45-100 W, 100-240 V, 50/60 Hz
    3-pin Fischer DC-In 90 W, 19 VDC
    Optional: Fisher DC-in: 12~32 V with BVA & Surge Protector

Security

  • TPM 2.0
  • Invisible Mode
  • Intel® vPro®
  • Optional: Smart Card Reader

Operating System

  • Windows 11 Pro

Dimensions [W×H×D]

  • 286 x 32 x 193 mm

Weight

  • ca. 1.86 kg

Protection class

  • IP65

Certification

  • MIL-STD-810H
  • MIL-STD-461G Ground Navy
  • Optional: MIL-STD-461G Ground Army
